Description
Specification
Mesh
- The panels comprise single 5mm horizontal wires and single 5mm vertical wires constructed in a 200mm x 50mm configuration.
- 200mm x 50mm mesh.
- 60mm x 60mm posts.
- 6mm horizontal wires and the vertical wires are set at 2 x 39mm and 3 x 19mm centres in a repeated series.
- The standard panel is 3000mm wide available in heights of 1800mm, 2000mm and 2400mm as
standard with an option for higher panels.
Posts
- Constructed in 60mm x 60mm x 2mm hollow section steel.
- Posts are set at 3000mm centres.
Post Options
- Baseplates or dowells.
- Plates for mounting on side of walls.
- Baseplates holed for fixing to concrete or top of walls.
- Cranked or straight extensions for barbed or razor wire.
- Cranked extensions to receive mesh panels.
- Doglegged cranks at base to go above walls.
Fixings
- Individual fixing clamps.
- Mountings: Steel retaining brackets.
- Bolts: Anti-vandal pin hex M8 x 40mm.
- Fixings: Threaded inserts set at 400mm max.
Finish
- Galvanised and polyester powder coated.
- Standard colours: RAL 6005 green, 9005 black, 5010 blue, 3000 red, 9010 white.
- Other colours: All other RAL colours available.
An installation service is available for the North Hertfordshire area.
